Description
Chocolate Scale / Multihead Weigher TY-M20L0.8 Main Function & Features:
1. Professional digital weighing module with high precision and good stability
2. Control system: MCU or PLC (optional).
3. Touch screen interface with different levels of authorized access; up to 16 different languages for choice; application
software upgraded through USB.
4. Factory parameters recovery function; 99 preset product parameters to meet different parameter program requirements.
5. Weighing hopper able to discharge in turn to effectively prevent products from blocking.
6. Weighing and counting function to meet diverse needs from customers.
7. Real-time display of amplitude of each vibration pan as well as product weight in each hopper to better monitor the running
status of the machine.
8. Machine body with SUS304/316 for option; IP65 dust and waterproof design.
9. Cleaning function: able to make the hoppers in opening state for easy daily cleaning and maintenance.
10. Two independent weighing system. With double upper storage hopper, double main vibrator and double discharge chute, two
different products can be weighed at the same by presetting two different operating parameters. It can also be used as a
normal 20-head weigher.
Specification
Model: TY-A-M20-1；TY-A-P20-1
Max Weighing (one hopper): 5-250g
Accuracy:x (0.5)
Max. Scale Interval:0.1g
Max. Speed:130 WPM
Hopper Volume:0.8L/ 0.5L
Control System:MCU / PLC
HMI:10’’ color touch screen
Power Supply:AC220V ±10% 50HZ/60HZ, 3KW
Packing Dimension:1,430(L)*1,430(W)*1,508(H)mm
Net Weight:500kg
Package weight:570kg
Specifications of 130WPM Chocolate Scale Multihead Weigher With 10 Inches Touch Screen
