SUS304 High-speed Intelligent RPP Rotary PremaSVacuum Bag Packaging Machine standing Pouch

PremaSVacuum Bag Packaging Machinetanding Pouch Features:

1. Tatol packaging automation, improved production efficiency and significantly reduced the product cost.

2. The machine can check the air pressure, temperature controller breakdown, opening status of the pouches to determine.It can also control the code printer, filling and hot-sealing device to avoid wasting of bags and products.

3. Meet a variety of packaging needs and cab be used with other equipment.

4. Filling system in intermittent operation and vacuum system in continuous operation.

5. Quick change of the pouches. The width of the bagging can be adjusted automatically at one time.

6. With product contact parts in SSUS304 or other material to conform with food hygiene and safety.

7. Convenient for cleaning. The vacuum chamber can be cleaned.

8. With pre-fabricated pouches, packaging material waste is low. Patterns on pouches are complete and good-looking and sealing is of good quality, enhancing the product level. When there is no product filling, there is no sealing and the pouches can be re-used.

9. Utilizing advanced PLC and POD electrical control system, the machine is able to adjust the angle and time of the pneumatic parts and human-machine interface is friendly with easy operation.

PremaSVacuum Bag Packaging Machinetanding Pouch Specifications:

Model TY-RP200 TY-RVP200

Packaging Speed 30~50 bpm 50 bpm

Bag Size 100-160(L)*100-230(W)mm 100-180(L)*120(W)mm

Packaging Weight 1-1.5kg 1-2kg

Sealing Type reticulate pattern sealing; double zipper sealing reticulate pattern sealing; double zipper sealing

Powder Supply 3 phase 380V 50HZ, 3KW 3 phase 380V 50HZ, 5KW

Air Consumption 5-8kgf/cm²; 0.4m³/min 0.6m³/min

Bag Type flat bag, stand-up bag, zipper bag flat bag, stand-up bag, zipper bag, paper bag, etc.

Net Weight 1,600kg 1,800kg

Machine Dimension 1,550(L)*1,350(W)*1,400(H)mm 1,480(L)*1,320(W)*1,510(H)mm
